Sawtooth wave jig

The sawtooth wave jig is suitable for processing coarse and medium-sized ores, with an upper limit of 50mm and a lower limit of 0.2-0.074mm, preferably 2-18mm. The sawtooth wave jig is often used to process coal mines, tungsten mines, tin mines, gold mines, iron mines, manganese mines, etc. The sawtooth wave jig is a re-selection ore dressing equipment. The jigging process is selected in the sawtooth wave jig. The basic principles of the jigs on the market are the same.

The core technology of the sawtooth wave jig is reflected in the stroke and the number of strokes. The stroke and the number of strokes determine the speed, acceleration and looseness of the water flow in the jig. The stroke and the number of strokes are related to the particle size, density and thickness of the bed of the selected material. It is appropriate to use a large stroke and a small number of strokes to select coarse-grained materials, while it is appropriate to use a small stroke and a large number of strokes to select fine-grained materials.

1. Compact structure, small footprint, and large processing capacity.

2. The cam mechanism is used to drive the sawtooth waveform jigging cycle curve, which makes the rising water flow uniform and the descending water flow rapid, effectively improving the recovery rate of fine-grained heavy minerals and achieving excellent beneficiation effect on fine-grained materials.

3. It has the characteristics of water saving and continuous operation.

4. The stroke and stroke frequency are easy to adjust, and the installation and maintenance are simple.
